4K Fanless Mini PC, Desktop Computer, Server, Intel I7 8550U / 8565U / 8559U / 8569U / 8650U, HUNSN BM14, WiFi, BT, DP, HDMI, LAN, Barebone, NO RAM, NO Storage, NO System
4K Fanless Mini PC, Desktop Computer, Server, Intel I7 8550U / 8565U / 8559U / 8569U / 8650U, HUNSN BM14, WiFi, BT, DP, HDMI, LAN, Barebone, NO RAM, NO Storage, NO System
Couldn't load pickup availability
Please note: This is a barebone only. A system memory, a storage drive and an operating system are needed to complete this system
Model Number: HUNSN BM14
Material: Aluminum
CPU: Intel Core I7 8565U/8559U/8569U/8650U, ship one of them
Memory: 2 x SODIMM DDR4-2400, Max. 64GB
Storage: 1 x mSata SSD, 1 x M.2 2280 SATA/NVME SSD, 1 x 2.5 inch SATA SSD/HDD
Audio Card: ALC892
Network Card: Intel I219-V
WiFi: 802.11ac 2.4 and 5Ghz
Bluetooth: 4.0/4.2
I/0 Port: DP, HDMI, 4 x USB 3.0, 4 x USB2.0, LAN, Spk, Mic
Power: DC100-240V AC/50-60Hz, DC 12V7A
Operating Temperature: 0°C~70°C Centigrade (32°F~140°F)
Storage Temperature: -20°C~80°C Centigrade (-68°F~176°F)
Relative Humidity: 10%~90% (non-condensing)
Vesa Mount: Optional
Weight: 2.5kgs
Measurement: 225 x 185 x 45mm
TDP: 15W
Cooling system: Fanless
Packing List: HUNSN BM14 mini pc, power supply, power cord, vertical stand, WiFi antennas, warranty card
Function: 1. Support diskless boot
2. Support Restore AC Power Loss
3. Support dual screen (DP and HDMI) for simultaneous display or synchronous different display
4. HDMI 1.4 4K: 4096x2304@30Hz
5. DP 1.2 4K: 4096x2304@60Hz, support DP to VAG transfer only (not support DP to HDMI transfer)
System Support: Windows 10/11, Linux Ubuntu, Vxworks etc
- Compact, fully functional, all the power and functionality of a desktop computer in a compact, stylish chassis, powered by the strong intel quad core i7 8565u/8559u/8569u/8650u processor. TDP is around 15w, if 8 hours one day, only 1-2 kWh electricity WEEKLY, power saving and space saving
- Please note, this is a barebone only. A system memory, a storage drive and an operating system are needed to complete this system
- Fanless passive cooling design, silent solution that’s ultra energy-efficient. the advanced fanless passive cooling design maximizes heat dissipation, meaning all operations can be conducted in absolute silence
- HUNSN BM14 designed with dp, hdmi, 4 x usb 3.0, 4 x usb2.0, lan, spk, mic, industrial aesthetic design and reasonable interface layout, support automatically power on after power failure
- Size at 225 x 185 x 45mm, 2.5kgs, 12v 7a power supply, with power cord, make sure to use a big brand memory and ssd/hdd with quality assurance, very powerful fanless mini pc
Specific uses for product | Everyday Use |
Brand | HUNSN |
Operating system | Ubuntu, Linux, Windows 10 |
Memory storage capacity | 64 GB |
CPU model | Core i7 8550U |
Colour | I7 8565U/8559U/8569U/8650U |
CPU manufacturer | Intel |
Wireless network technology | Wi-Fi |
Connectivity technology | Powerline |
Total USB ports | 8 |
